Functions & Features
●High Precise measuring performance.
●Two ways of measuring: PE-testing and EE-testing.
●EE-test function (Echo to Echo), measuring the thickness of workpiece through the coating on its surface.
●Large measuring range with B scan function, showing graphs directly.
●High-speed of reflection and measuring: Application with 2 industrial control CPU systems allow independent work of
instrument measuring control and the data processing.
●Measuring sound velocity: according to the known thickness of the object, sound velocity of it can be measured
directly.
●Large memory to save 128,000 groups of measuring data and 255 groups of B Scan graphs.
●PC Software for data transmission, analysis and measurement reports printing
●High-definition color display.
●Integrated with a 4mm calibration block.
●With Calendar and clock, auto recording measuring date and time.
●With Auto power off function.
Measuring range(mm): 0.75～1000.00mm
Frequency (MHz): 0.5～15.0MHz
Resolution(mm): 0.01mm
Accuracy(mm): ± 0.1 mm ( H ＜10mm)
±(0.5%H+0.01) (H＞10mm)
H refers to the thickness of testing piece
Max coating thickness: 1mm
Measuring range (through coating): 2～150mm
Velocity range(m/s): 1000～9999m/s
Type of probe: Double crystal
Storage: 128,000 groups (measuring data); 255 groups( B scan grraph)
Display: 2.4" High-definition color display
Display units: mm & inch
Output port: Mini USB
Operating temperature: -20℃～50℃
Power supply: 3 * AA
Dimensions: 150×75×32（mm）
Weight: 275g
